Cámara vigilancia Domo Dahua metálica / IR 30mts / 4K – IP67

SKU: DH-HAC-HDW1800TLN-A

Neto: $35.915IVA: $6.824Total: $42.739

Brand:

  • Dahua
Disponibilidad: En Stock

  • Resolución: 4K
  • Tamaño de lente: 2.8mm opcional 3.6mm
  • Soporte grabación: CVI/CVBS/AHD/TVI switchable
  • Alcance nocturno: 30 metros
  • Grado protección ambiente: IP67.
  • Tipo cámara: Domo
  • Material: Metálica/Plástica
SKU: DH-HAC-HDW1800TLN-A Categorías: , ,
Camera
Image Sensor 1/2.7 inch CMOS
Effective Pixels 3840 (H)× 2160 (V), 4K
Scanning System Progressive
Electronic Shutter Speed PAL: 1/25s–1/100000s
NTSC: 1/30s–1/100000s
S/N Ratio >65dB
Minimum Illumination 0.03Lux/F2.0, 30IRE, 0Lux IR on
Fill Light Working Distance 30 m (98.4 ft)
IR On/Off Control Auto; manual
IR LED Number 1
Pan/Tilt/Rotation Range Pan: 0°–360°
Tilt: 0°–78°
Rotation: 0°–360°
Lens
Lens Type Fixed-focal
Mount Type M12
Focal Length 2.8mm; 3.6mm
Max. Aperture F2.0
Angle of View 2.8mm: 125° x 105° x 56° (diagonal x horizontal x vertical)
3.6mm: 104° x 87° x 47° (diagonal x horizontal x vertical)
Iris Type Fixed iris
Close Focus Distance 2.8mm: 1.0 m (3.3 ft)
3.6mm: 1.9 m (6.2 ft)
DORI Distance Lens Detect Observe Recognize Identify
2.8mm 74.7 m (245.1 ft) 29.9 m (98.1 ft) 14.9 m (48.9ft) 7.5 m

(24.6 ft)

3.6mm 106.7 m (350.1 ft) 42.7 m (140.1 ft) 21.3 m (69.9 ft) 10.7 m (35.1 ft)
Video
Frame Rate CVI: 4K@25/30fps; 4K@15fps; 5M@20fps; 4M@25fps/30fps;
AHD: 4K@15fps;
TVI: 4K@15fps;
CVBS: 960H
Resolution 4K (3840 × 2160); 5M (2592 × 1944); 4M (2560 × 1440); 960H (960 × 576/960 × 480)
Day/Night Auto switch by ICR
BLC BLC/HLC/WDR
WDR DWDR
White Balance Auto; manual
Gain Control Auto; manual
Noise Reduction 2D NR
Smart IR Yes
Mirror Off/On
Privacy Masking Off/On (8 area, rectangle)
Certifications
Certifications CE (EN55032, EN55024, EN50130-4,EN60950-1)
FCC (CFR 47 FCC Part 15 subpartB, ANSI C63.4-2014)
UL (UL60950-1+CAN/CSA C22.2 No.60950-1)
Port
Video Output Video output choices of CVI/TVI/AHD/CVBS by one BNC port
Audio Input One channel, built-in mic (-A)
Power
Power Supply 12V ±30% DC
Power Consumption Max 4.3W (12V DC, IR on)
Environment
Operating Temperature -40°C to +60°C (-40°F to 140°F);

<95% (non-condensation)

Storage Temperature -40°C to +60°C (-40°F to 140°F);

<95% (non-condensation)

Protection Grade IP67
Structure
Casing Cover: plastic; inner core: metal
Camera Dimensions Φ97 mm × 85.8 mm (Φ3.82″×3.38″)
Net Weight 0.3Kg (0.66lb)
Gross Weight 0.38Kg (0.84lb)
